SAPPHIRE Radeon™ GRAPHICS CARD

Sapphire Radeon™ R9 380 2G D5 (ITX Compact)

The SAPPHIRE ITX Compact R9 380 edition has been developed especially for small form factor PC systems. This model features a shorter PCB, measuring only 171mm long, and an efficient heatpipe cooler with a single dual-ball bearing fan.  With its 2GB frame buffer it is no slouch despite its small size. Sharing the latest AMD GCN core with the NITRO and Dual-X models, the SAPPHIRE ITX Compact R9 380 supports DirectX 12, TrueAudio, AMD FreeSync and Ultra HD. With a SAPPHIRE Performance Index of 3 it is guaranteed to deliver a great gaming experience in high detail at 1080p and beyond.


Two-ball bearing

Dual ball bearings on the fan spindles ensure smooth running and long life and are designed to keep out dust. A quiet cooling solution, Two ball-bearing fan features a high-efficiency blade design.




Black Diamond Choke

To ensure best stability SAPPHIRE special products utilize Black Diamond Chokes. The choke is an important component of the power regulation on a graphics card, and the SAPPHIRE Black Diamond Choke with integral heatsink runs 10% cooler and with 25% more power efficiency than a normal choke.


16K Hours Capacitor

High quality aluminum-made long life capacitor lengthens the life time of the product. Improved reliability and better overclocking are possible by using only high-polymer, aluminum capacitors which possess far superior characteristics than regular aluminum capacitor for a longer product life. When operational temperatures drop by 20°C, the product life span is extended by a factor of ten, when the operational temperature increases by 20°C, the product life span only decreases by 10%.


Frame Rate Target Control

Frame Rate Target Control (FRTC) enables users to set a target maximum frame rate when playing an application in full screen mode; the benefit being that FRTC can reduce GPU power consumption (great for games running at frame rates much higher than the display refresh rate) and therefore reduce heat generation and fan speeds/noise on the graphics card.

Frame Rate Target Control caps performance not only in 3D rendered in-game scenes, but also in splash screens, loading screens and menus, where frame rates can often run needlessly into the hundreds of FPS. Users might wish to set a very high cap just to limit wasteful FPS like that seen in menus and such, while still taking advantage of the responsiveness given by FPS well beyond 60.


DirectX® 12

DirectX® 12 is a new, “console-like” graphics API from Microsoft® that empowers game developers with more direct and obvious control of PC hardware. This direct or “explicit” control better exposes the hardware resources of AMD Radeon™ GPUs to yield higher hardware throughput and, ultimately, more performance for users. To put it simply: much more efficient hardware through smarter software! At the discretion of a game developer, this superior efficiency can be spent on higher framerates, lower latency (VR), lower power consumption, better image quality, or some calculated balance of all four. In any scenario, gamers stand to benefit greatly from choosing AMD hardware to run their favorite DirectX® 12 game.


AMD Freesync technology

No stuttering. No tearing. Just gaming.

AMD FreeSync™ technology allows a compatible graphics card and monitor to dynamically change frame rates for the optimum display quality without tearing or stuay.

Industry-Standard Displayport

Freesync uses industry-standard displayport Adaptive-Sync Eliminates screen tearing without all the usual lag and latency

  • Synchronizes the refresh rate of a compatible monitor to the frame rate of your content, however much it varies
  • Monitor partners are validating with drivers from AMD now

AMD Eyefinity Technology

Multidisplay technology for gaming, productivity and entertainment

We are taking you beyond the boundaries of traditional PC displays. AMD Eyefinity technology expands the traditional limits of desktop computing by multiplying your screen area. With multiple monitors, games become more immersive, workstations become more useful and you become more productive (an average of 42% more productive according to one study).

Take your PC games to the next level of reality and immersion. Most modern games look great on three screens, and only AMD Radeon™ graphics offer you the ability to play across five screens for an eye-popping gaming experience. Other combinations and configurations with up to six screens work too.1 Create your dream display.


GPU 1792 Stream Processors
28 nm
Graphics Core Next (GCN)
980 MHz  Engine Clock
Interface PCI-Express 3.0
Memory 256 bit Memory Bus
GDDR5 Memory Type
5600 MHz, Effective
2 GB Size
BIOS Support Legacy BIOS
UEFI BIOS
Displays Maximum 4 Outputs
Output 1 x DVI-D
1 x HDMI
2 x Mini DisplayPort
Resolution 4096X2160 Pixel DisplayPort Resolution
2560x1600 Pixel Dual Link DVI Resolution
1920x1200 Pixel Single Link DVI Resolution
2160P HDMI Resolution
API OpenGL® 4.5
OpenCL 2.0
DirectX® 12
Shader Model 5.0
Feature AMD CrossFire
AMD PowerTune
AMD ZeroCore Power Technology
FreeSync Technology
AMD Eyefinity
Quad HD Display (4K*2K Support)
Video Codec Engine (VCE)
AMD HD3D Technology
Black Diamond Choke
Dual BIOS
AMD Liquid VR Technology
AMD Virtual Super Resolution(VSR)
AMD TrueAudio Technology
Cooling Single fan
Two ball bearing
Form Factor 2 Part Slot Occupied
6.7 x 4.57 x 1.46 Dimension /Inch
170 x 116.15 x 37 Dimension /mm
Power Consumption 225W
OS Windows 10 Windows 8/8.1 Windows 7
System Requirement 500 Watt Power Supply (Suggestion)
1 x 8-pin AUX Power Connector
2 x 8-pin AUX Power Connector is required for CrossFireX™ system.
CD-ROM or DVD-ROM drive for installing software
PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.
  • Specifications provided here are for guidance only. Please check with your regional distributor or dealer for latest specifications.
  • Colors of PCB or other components may differ from those illustrated.
  • SAPPHIRE reserves the right to update or revise specifications without prior notice.
  • All trademarks and logos are acknowledged as the property of their respective holders.
Select Your Operating System:

AMD Official Radeon Driver

Obtain the Latest AMD Radeon Official Driver Utility Latest Version
Recommend for the systems running Microsoft Windows to obtain the latest official driver for AMD Graphics product. Click on the Download ​link and a web browser prompt should appear. Select Run from the prompt.

Download

Windows Vista Windows 7 Windows 8/8.1 Windows 10

AMD Radeon Software

AMD Radeon Software Crimson Edition 17.7.1 Driver for Windows® 8.1 64-bit​ 17.10.3211.1031
Article Number: RN-WIN-RADEONCRIMSONRELIVE-17.7.1
​Radeon Software Crimson ReLive Edition is AMD's advanced graphics software for enabling high-performance gaming and engaging VR experiences. Create, capture, and share your remarkable moments. Effortlessly boost performance and efficiency. Experience Radeon Software with industry-leading user satisfaction, rigorously-tested stability, comprehensive certification, and more.

Radeon Software Crimson ReLive Edition 17.7.1 Highlights

Support For

    • Radeon RX 460/470 Series Graphics-based mining cards
    • Radeon RX 550/560 Series Graphics

Fixed Issues

    • Fixed a bug causing crashes on Tekken 7 (Chapter 5) on Radeon RX 380 Series graphics products.
    • Fixed a bug causing crashes on FFXIV and Little Nightmares on Radeon RX 300 Series graphics products.
    • Fixed an issue causing crashes with Adobe Lightroom CC 2015.10

Known Issues

    • Graphical corruption may be experienced in Tom Clancy's™: Rainbow Six Siege when MSAA is enabled.
    • A small number of apps may experience issues with Borderless Fullscreen mode and AMD FreeSync™ technology if other applications or game launchers are running on the primary screen in the background.
    • Counter-Strike™: Global Offensive and World of Warcraft™ may experience flickering or performance issues the first time the game is launched on a system boot with AMD FreeSync™ technology enabled. Workarounds include exiting and restarting the application or task switching (alt+tab) in and out of the game to fix the issue.
    • Tekken 7 may experience a crash (Chapter 13) on some Radeon RX 380 Series graphics products.

Known Issues for Radeon ReLive

    • The XBOX™ DVR application may cause conflicts with Radeon ReLive, users are suggested to disable XBOX™ DVR if Radeon ReLive is experiencing issues
    • Radeon ReLive may fail to install on AMD APU Family products or experience a system hang or failure to record when using the recording feature on AMD APU Family products.
    • Radeon ReLive may intermittently fail to work after performing task switches of applications. A work around is to disable and then enable the feature in Radeon Software.
    • Radeon ReLive may exhibit corruption in recordings when capturing Microsoft Office applications.
    • Radeon ReLive may experience recording or streaming issues when task switching using ALT+TAB.

Download

File Size: 400MB

Windows 8.1 (64-bit)
AMD Radeon Software Crimson Relive Edition 17.7.2 Driver for Windows® 7 64-bit​ 17.30.1041
Article Number: RN-WIN-RADEONCRIMSONRELIVE-17.7.2

​​Radeon Software Crimson ReLive Edition is AMD's advanced graphics software for enabling high-performance gaming and engaging VR experiences. Create, capture, and share your remarkable moments. Effortlessly boost performance and efficiency. Experience Radeon Software with industry-leading user satisfaction, rigorously-tested stability, comprehensive certification, and more.

Radeon Software Crimson ReLive Edition 17.7.2 Highlights

New Features and Improvements

Radeon Settings

    • Radeon Additional Settings has been retired and its previously supported controls for Switchable Graphics, Color Depth and Pixel Format have all been moved into Radeon Settings.

Radeon ReLive (1)

    • Now supports bitrates up to 100Mbps for recording or capturing.
    • Added new controls for camera transparency.
    • Optimized memory usage for lower overhead while recording or capturing.
    • Added new notifications for Instant Replay Saving, Recording Timers in Overlay Toolbar and Network Connectivity Issues when streaming.
    • Enhanced Audio Controls: Radeon Software Crimson ReLive Edition now has support for customizable microphone volume controls, audio boost for captured replays and push to talk (mouse + keyboard) support for microphone.

Radeon Chill(2)

    • Now supports DirectX®12 and Vulkan™. For more details on new and supported games visit http://www.radeon.com/chill.
    • Now supports Multi-GPU.
    • Now supports Hybrid Graphics system configurations.
    • Now supports Radeon XConnect™ Technology system configurations.

Enhanced Sync(3)

    • Enhanced Sync is a display technology which helps minimize screen tearing while decreasing latency and stuttering at an unlocked frame rate. Enhanced Sync is available in Radeon Settings Game Manager under the "Wait for Vertical Refresh" drop down menu.

Per-Display Color Controls(4)

    • Per-Display Color Controls are now available in the display tab of Radeon Settings allowing users to configure Brightness, Hue, Contrast and Saturation.

Game Responsiveness(5)

    • Radeon Software Crimson ReLive Edition 17.7.2 features optimizations for improved gaming responsiveness in DirectX®9 and select DirectX®11 gaming titles.

Radeon WattMan(6)

    • Now supports memory underclocking.
    • Now supports power state controls.

Frame Rate Target Control(7)

    • Now supports DirectX®12 and Multi-GPU.

Shader Cache(8)

    • Shader Cache is now supported for select DirectX®9 titles

Radeon Software Vanguard Beta Program

    • The Radeon Software Vanguard Beta Tester program aims at opening a channel for selected participants to work directly with AMD, giving a voice and platform to share their passion for Radeon Software. For more information about Radeon Software Vanguard visit www.Radeon.com/Vanguard.

Radeon.com Feedback and Feature Voting

    • Radeon Software feedback and feature voting has been updated. Visit www.radeon.com/feedback to provide Radeon Software feedback and vote on future Radeon Software features.

Fixed Issues

    • Mass Effect™: Andromeda may experience incorrect colors when using an HDR display and a secondary SDR display connected in extended mode.
    • Fan speeds when using Radeon WattMan may remain elevated and not drop back to idle states after 3D workloads.
    • Some video playback applications may experience stutter in fullscreen with AMD FreeSync™ technology enabled.
    • Radeon ReLive may exhibit corruption in recordings when capturing Microsoft Office applications.
    • Radeon ReLive may experience recording or streaming issues when task switching using ALT+TAB.

Known Issues

    • Radeon WattMan fan settings may reset to defaults on Radeon Software upgrade to 17.7.2.
    • Tekken™ 7 may experience a crash (Chapter 13) on some Radeon RX 380 Series graphics products.
    • GPU Scaling may fail to work on some DirectX®11 applications.
    • 4x Multi-GPU system configurations may fail to enable AMD CrossFire technology mode due to a missing toggle in Radeon Settings.
    • Some protected content applications may experience an HDCP error code while playing BluRay content. A workaround is to unplug and re-plug the connected display or turn the display off and then back on.

Download

File Size: 453MB

Windows 7 (64-bit)
AMD Radeon Software Crimson Relive Edition 17.7.2 Driver for Windows® 10 64-bit​ 17.30.1041
Article Number: RN-WIN-RADEONCRIMSONRELIVE-17.7.2

​​Radeon Software Crimson ReLive Edition is AMD's advanced graphics software for enabling high-performance gaming and engaging VR experiences. Create, capture, and share your remarkable moments. Effortlessly boost performance and efficiency. Experience Radeon Software with industry-leading user satisfaction, rigorously-tested stability, comprehensive certification, and more.

Radeon Software Crimson ReLive Edition 17.7.2 Highlights

New Features and Improvements

Radeon Settings

    • Radeon Additional Settings has been retired and its previously supported controls for Switchable Graphics, Color Depth and Pixel Format have all been moved into Radeon Settings.

Radeon ReLive (1)

    • Now supports bitrates up to 100Mbps for recording or capturing.
    • Added new controls for camera transparency.
    • Optimized memory usage for lower overhead while recording or capturing.
    • Added new notifications for Instant Replay Saving, Recording Timers in Overlay Toolbar and Network Connectivity Issues when streaming.
    • Enhanced Audio Controls: Radeon Software Crimson ReLive Edition now has support for customizable microphone volume controls, audio boost for captured replays and push to talk (mouse + keyboard) support for microphone.

Radeon Chill(2)

    • Now supports DirectX®12 and Vulkan™. For more details on new and supported games visit http://www.radeon.com/chill.
    • Now supports Multi-GPU.
    • Now supports Hybrid Graphics system configurations.
    • Now supports Radeon XConnect™ Technology system configurations.

Enhanced Sync(3)

    • Enhanced Sync is a display technology which helps minimize screen tearing while decreasing latency and stuttering at an unlocked frame rate. Enhanced Sync is available in Radeon Settings Game Manager under the "Wait for Vertical Refresh" drop down menu.

Per-Display Color Controls(4)

    • Per-Display Color Controls are now available in the display tab of Radeon Settings allowing users to configure Brightness, Hue, Contrast and Saturation.

Game Responsiveness(5)

    • Radeon Software Crimson ReLive Edition 17.7.2 features optimizations for improved gaming responsiveness in DirectX®9 and select DirectX®11 gaming titles.

Radeon WattMan(6)

    • Now supports memory underclocking.
    • Now supports power state controls.

Frame Rate Target Control(7)

    • Now supports DirectX®12 and Multi-GPU.

Shader Cache(8)

    • Shader Cache is now supported for select DirectX®9 titles

Radeon Software Vanguard Beta Program

    • The Radeon Software Vanguard Beta Tester program aims at opening a channel for selected participants to work directly with AMD, giving a voice and platform to share their passion for Radeon Software. For more information about Radeon Software Vanguard visit www.Radeon.com/Vanguard.

Radeon.com Feedback and Feature Voting

    • Radeon Software feedback and feature voting has been updated. Visit www.radeon.com/feedback to provide Radeon Software feedback and vote on future Radeon Software features.

Fixed Issues

    • Mass Effect™: Andromeda may experience incorrect colors when using an HDR display and a secondary SDR display connected in extended mode.
    • Fan speeds when using Radeon WattMan may remain elevated and not drop back to idle states after 3D workloads.
    • Some video playback applications may experience stutter in fullscreen with AMD FreeSync™ technology enabled.
    • Radeon ReLive may exhibit corruption in recordings when capturing Microsoft Office applications.
    • Radeon ReLive may experience recording or streaming issues when task switching using ALT+TAB.

Known Issues

    • Radeon WattMan fan settings may reset to defaults on Radeon Software upgrade to 17.7.2.
    • Tekken™ 7 may experience a crash (Chapter 13) on some Radeon RX 380 Series graphics products.
    • GPU Scaling may fail to work on some DirectX®11 applications.
    • 4x Multi-GPU system configurations may fail to enable AMD CrossFire technology mode due to a missing toggle in Radeon Settings.
    • Some protected content applications may experience an HDCP error code while playing BluRay content. A workaround is to unplug and re-plug the connected display or turn the display off and then back on.

Download

File Size: 463MB

Windows 10 (64-bit)
Show All Downloads

Utility

TriXX OC Utility v5.2.1

TriXX is regularly updated to provide support for new releases of graphics cards and GPU families as well as enhancements to the tool.

New features:

  • New look and interface
  • Now supports over-volting on Radeon R300 series
  • Now supports HBM memory overclock on FURY cards
  • Now supports over-volt on FURY cards
  • Minimise TriXX to task bar

Download

File Size: 1MB

Windows 7 (32-bit) Windows 7 (64-bit) Windows 8.1 (32-bit) Windows 8.1 (64-bit) Windows 10 (32-bit) Windows 10 (64-bit)
TriXX OC Utility V5.0.0

SAPPHIRE TriXX is the optimal overclocking utility for your AMD RADEON™ R200 , R300 and FURY series. The features include

  • Performance Tune Memory and GPU Clock Speeds
  • Over and Under Voltage adjustment
  • Save configurations
  • Graphical H/W Monitor
  • H/W log file
  • Feedback option

Download

File Size: 1MB

Windows 7 (32-bit) Windows 7 (64-bit) Windows 8.1 (32-bit) Windows 8.1 (64-bit)

Graphic Card User Guide

Graphic Card User Guide V1.0

Radeon R9 380 series User manual_English version

Download

File Size: 624KB
